Product Description:
The 1200C High-Temperature Vacuum Furnace is perfect for industries such as aerospace, automotive, and electronics, where precision and reliability are paramount. Its advanced vacuum technology minimizes oxidation and contamination, allowing for high-quality sintering, annealing, and fusion processes.
the furnace produced by nanyang sinowin industry is designed to operate at peak temperatures of up to 1200 degrees Celsius, this high-performance vacuum furnace ensures exceptional control over heat treatment processes, enabling optimal results for a variety of materials.With user-friendly controls and robust construction, the 1200C High-Temperature Vacuum Furnace offers reliable performance and durability. Whether you are conducting research and development or high-volume production, this furnace will meet and exceed your needs.
Technical Parameters of 1200C High-Temperature Vacuum Furnace:
1200C High-Temperature Vacuum Furnace |
|||
| Main Specifications: | |||
| Inside Chamber Size | Support customized upon request | ||
| Standard Working Temperature | 1100oC ( continuous ) | ||
| Maximum Working Temperature | 1200oC ( < 3 hrs) | ||
| Furnace Atmosphere | Nitrogen, Argon and other inert gases | ||
| Vacuum degree ultimate vacuum: | 1X10-3PA | ||
| Temperature Control | 50 steps programmable and PID automatic control | ||
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) | ||
| Temperature Accuracy | +/- 1 .C | ||
| Furnace structure | Double shell with fan cooling | ||
| Heating Element | Kanthal resistance wire | ||
| Thermocouples | K type | ||
| Working Voltage | AC 220-440V Single/Three Phases 60/50 Hz (or according to your requirement) | ||
| Max. Power | 1.5-100KW | ||
| Outside Size | Based on the chamber size | ||
| Net Weight | Based on the chamber size | ||
| Brief Description: | |||
| SWVF series box atmosphere furnace can protect materials from oxidation and decarburization with flowing Nitrogen, Argon and other Inert gas. It’s an ideal furnace for sintering, reducing with inert-atmosphere in labs of university, Research Institution and industrial company. | |||
| Standard package | |||
| Part description | Quantity | ||
| Thermal couple | 1 pc | ||
| Inlet/outlet,valves | 1 set | ||
| Flow meter | 1 pc | ||
| Vacuum gauge | 1 pc | ||
| Vacuum pump | 1 set | ||
| Furnace door block | 1 pc | ||
| Thermal gloves | 1 pair | ||
| Operation manual | 1 pc | ||
| Standard Sizes: | |||
| Model | Chamber size(WxHSWAmm) | Max. Temperature | |
| SWVF-1200A | 150x150x150mm | 1250.C | |
| SWVF-1200A | 200x200x200mm | 1250.C | |
| SWVF-1200A | 200x200x300mm | 1250.C | |
| SWVF-1200A | 250x250x300mm | 1250.C | |
| SWVF-1200A | 300x300x400mm | 1250.C | |
| SWVF-1200A | 450x450x500mm | 1250.C | |
| SWVF-1200A | 600x600x600mm | 1250.C | |
Choose the 1200C High-Temperature Vacuum Furnace produced by nanyang sinowin industry for your thermal processing needs and experience unmatched quality and innovation in high-temperature technology. Whether you’re in research, manufacturing, or materials science, this furnace stands out as an indispensable tool in your operations. Donot hesitate to Contact us at once for more information ,NanYang Sinowin Industry are not only a supplier but a reliable partner to assist you the safe solutions of the heat treatment .
