Product Description: 1400 Degree Ceramic Bottom Loading Furnace
The 1400 Degree Ceramic Bottom Loading Furnace is a high-temperature heating muffle furnace designed for firing ceramics and other materials. The furnace features a robust ceramic base that ensures even heat distribution, minimizing temperature fluctuations during the heating process. This precision is vital for achieving desirable results in any heat-sensitive application.
How Does It Work?
This furnace operates by utilizing a combination of high-quality heating elements and an intuitive control system, allowing users to set and maintain their desired temperature with accuracy. The internal design includes insulation that retains heat effectively, ensuring energy efficiency while maximizing performance. The furnace is equipped with safety features, including an auto shut-off mechanism and temperature monitoring systems, making it safe for any environment.
Applications of the 1400 Degree Ceramic Bottom Loading Furnace
The versatility of the 1400 Degree Ceramic Bottom Loading Furnace makes it suitable for a wide range of applications. It is ideal for ceramics artists looking to create intricate pottery or sculptures, as well as for researchers conducting experiments involving high-temperature materials. In addition, it is frequently used in dental labs for porcelain and metal applications, ensuring high-quality results in dental restorations.
Technical Parameter of the 1400 Degree Ceramic Bottom Loading Furnace :
| 1400BL ceramic bottom loading furnace | |
| Main Specifications: | |
| Inside Chamber Size | 250/300MM Dia/H |
| Standard Working Temperature | 1350oC ( continuous ) |
| Maximum Working Temperature | 1400oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Heating Element | High quality SiC heater |
| Working Voltage | AC 380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8 KW |
| Outside Size | 700 x 800 x 1600 mm |
| Net Weight | 280 Kg |
| SW-1400BL The single zone, high temperature, bottom loading furnace is capable of operating at temperatures.The furnace utilizes 1500oC High quality SiC heater positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramic-fiber, high temperature insulation. It is an ideal tool for materials annealing and sintering. | |
the 1400 Degree Ceramic Bottom Loading Furnace is a vital instrument that guarantees precision, safety, and versatility across multiple applications. Whether you are a hobbyist or a professional, this furnace is designed to meet your high-temperature heating needs efficiently and effectively.
Upgrade your workspace today with our top-of-the-line furnace and experience the difference in quality and performance.Donot hesitate to Contact us at once for any further information ,we are not only a supplier but a reliable partner to assist you the safe solutions of the heat treatment
Technical Parameter of the 1400 Degree Ceramic Bottom Loading Furnace :
| 1400BL ceramic bottom loading furnace | |
| Main Specifications: | |
| Inside Chamber Size | 250/300MM Dia/H |
| Standard Working Temperature | 1350oC ( continuous ) |
| Maximum Working Temperature | 1400oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Heating Element | High quality SiC heater |
| Working Voltage | AC 380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8 KW |
| Outside Size | 700 x 800 x 1600 mm |
| Net Weight | 280 Kg |
| SW-1400BL The single zone, high temperature, bottom loading furnace is capable of operating at temperatures.The furnace utilizes 1500oC High quality SiC heater positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramic-fiber, high temperature insulation. It is an ideal tool for materials annealing and sintering. | |
| Model | Chamber size (WXHXDmm OR DIA/Hmm) |
| SW-1400BL | 120x120x130mm or dia120H150mm |
| SW-1400BL | 150x150x150mm or dia150H200mm |
| SW-1400BL | 200x200x200mm or dia200H200mm |
| SW-1400BL | 200x200x300mm or dia200H300mm |
| SW-1400BL | 250x250x300mm or dia250H300mm |
| SW-1400BL | 300x300x400mm or dia300H400mm |
| SW-1400BL | 450x450x500mm or dia450H500mm |
