Product Description: 1700C Laboratory Crucible Muffle Furnace with MoSi2 Heaters
The 1700C Laboratory Crucible Muffle Furnace is designed for high-temperature applications in laboratory settings. Engineered to withstand extreme conditions, this furnace can reach temperatures up to 1700 degrees Celsius, making it ideal for a wide range of scientific and industrial purposes.
This muffle furnace is perfect for various applications, including materials testing, metal casting, ceramics, glass melting, and sintering processes. It is widely used in research and development labs, quality control laboratories, and educational institutions, providing researchers and students alike with the tools necessary for innovative exploration.
How It Works:
The 1700C Laboratory Crucible Muffle Furnace operates by utilizing advanced heating elements and insulation materials that ensure uniform heating distribution within the chamber. The intuitive temperature control system allows users to set and maintain precise temperatures, which is crucial for accurate experimentation and processing. Its robust construction and efficient design minimize heat loss, ensuring energy efficiency and reliability during operation.
Technical Parameter of the 1700C Laboratory Crucible Muffle Furnace
1700C Laboratory Crucible Muffle Furnace |
|
| Main Specifications: | |
| Inside Chamber Size | DIA100/150MM 150/200MM 180/220MM 250/300MM |
| Standard Working Temperature | 1600oC ( continuous ) |
| Maximum Working Temperature | 1700oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Furnace structure | Double shell with fan cooling |
| Heating Element | MoSi2 heating elements |
| Thermocouples | B type |
| Working Voltage | AC 220/380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8KW |
| Outside Size | 550 x 540 x 820 mm |
| Net Weight | 170 Kg |
| SW series box furnaces are the most cost effective bench-top high temperature muffle furnace. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements with special design, and furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy +/-1 deg oC and 30 segments programmable. It is an ideal tool for materials annealing and sintering in your research laboratory. | |
| Standard package included with the furnace | |
| Part description | Quantity |
| High Temperature Muffle Furnace | 1 pc |
| Heating Element, spare parts | 2 pcs |
| B type Thermocouples | 1 pc |
| Al2O3 Sample Plate | 1 pc |
| Al2O3 Furnace Door Block | 1 pc |
| Crucible Clip | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 pc |
| Standard Sizes: | |
| Model | Chamber size(WxHxDmm or DIAxH) |
| SW-1700CF | 100x100x100mm or 100/150mm |
| SW-1700CF | 120x120x130mm or 120/150mm |
| SW-1700CF | 150x150x150mm or 150/200mm |
| SW-1700CF | 200x200x200mm or 180/220mm |
| SW-1700CF | 200x200x300mm or 250/300mm |
With the 1700C Laboratory Crucible Muffle Furnace, you gain access to a powerful tool designed to meet the rigorous demands of your laboratory tasks. Experience the precision and dependability of our muffle furnace and elevate your research capabilities to new heights.
Choose the 1700C Laboratory Crucible Muffle Furnace for unparalleled performance and exceptional results in high-temperature applications.
Donot hesitate to Contact us at once for more information ,NanYang Sinowin Industry are not only a supplier but a reliable partner to assist you the safe solutions of the heat treatment
Technical Parameter of the 1700C Laboratory Crucible Muffle Furnace
1700C Laboratory Crucible Muffle Furnace |
|
| Main Specifications: | |
| Inside Chamber Size | DIA100/150MM 150/200MM 180/220MM 250/300MM |
| Standard Working Temperature | 1600oC ( continuous ) |
| Maximum Working Temperature | 1700oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Furnace structure | Double shell with fan cooling |
| Heating Element | MoSi2 heating elements |
| Thermocouples | B type |
| Working Voltage | AC 220/380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8KW |
| Outside Size | 550 x 540 x 820 mm |
| Net Weight | 170 Kg |
| SW series box furnaces are the most cost effective bench-top high temperature muffle furnace. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements with special design, and furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy +/-1 deg oC and 30 segments programmable. It is an ideal tool for materials annealing and sintering in your research laboratory. | |
| Standard package included with the furnace | |
| Part description | Quantity |
| High Temperature Muffle Furnace | 1 pc |
| Heating Element, spare parts | 2 pcs |
| B type Thermocouples | 1 pc |
| Al2O3 Sample Plate | 1 pc |
| Al2O3 Furnace Door Block | 1 pc |
| Crucible Clip | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 pc |
| Standard Sizes: | |
| Model | Chamber size(WxHxDmm or DIAxH) |
| SW-1700CF | 100x100x100mm or 100/150mm |
| SW-1700CF | 120x120x130mm or 120/150mm |
| SW-1700CF | 150x150x150mm or 150/200mm |
| SW-1700CF | 200x200x200mm or 180/220mm |
| SW-1700CF | 200x200x300mm or 250/300mm |
