Product Description: High-Temperature 1800 Degree Box Annealing Furnace for heat treatment
The High-Temperature 1800 Degree Box Annealing Furnace designed and produced by nanyang sinow industry is used for heat treatment applications. Designed to meet the rigorous demands of metalworking and materials processing, this furnace operates at an impressive maximum temperature of 1800 degrees, making it ideal for various annealing processes.
The High-Temperature 1800 Degree Box Annealing Furnace features advanced insulation technology, ensuring optimal heat retention and energy efficiency during operation. Its spacious interior allows for the processing of larger components, while the precision temperature control system guarantees uniform heating throughout the chamber. This is essential for achieving consistent results in your annealing projects.
Constructed from durable materials, the High-Temperature 1800 Degree Box Annealing Furnace is built to withstand the rigors of continuous use in demanding environments. Its user-friendly interface and safety features make it an essential addition to any workshop or manufacturing facility focused on quality and reliability.
Whether you are involved in the aerospace, automotive, or metal fabrication industries, the High-Temperature 1800 Degree Box Annealing Furnace is your go-to solution for high-performance annealing processes.
Key Features:
- Maximum operating temperature of 1800 degrees
- Advanced insulation technology for energy efficiency
- Spacious heating chamber for larger components
- Precision temperature control for uniform heat distribution
- Durable construction for long-lasting performance
Choose the High-Temperature 1800 Degree Box Annealing Furnace for your high-temperature annealing needs and experience the difference in quality and efficiency.
Technical Parameters of the High-Temperature 1800 Degree Box Annealing Furnace for heat treatment:
High-Temperature 1800 Degree Box Annealing Furnace |
|
| Main Specifications: | |
| Inside Chamber Size | DIA100/150MM 150/200MM 180/220MM 250/300MM |
| Standard Working Temperature | 1700oC ( continuous ) |
| Maximum Working Temperature | 1820oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Furnace structure | Double shell with fan cooling |
| Heating Element | MoSi2 heating elements |
| Thermocouples | B type |
| Working Voltage | AC 220/380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8KW |
| Outside Size | 550 x 540 x 820 mm |
| Net Weight | 170 Kg |
| SW series box furnaces are the most cost effective bench-top high temperature muffle furnace. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements with special design, and furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy +/-1 deg oC and 30 segments programmable. It is an ideal tool for materials annealing and sintering in your research laboratory. | |
| Standard package included with the furnace | |
| Part description | Quantity |
| High Temperature Muffle Furnace | 1 pc |
| Heating Element, spare parts | 2 pcs |
| B type Thermocouples | 1 pc |
| Al2O3 Sample Plate | 1 pc |
| Al2O3 Furnace Door Block | 1 pc |
| Crucible Clip | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 pc |
| Standard Sizes: | |
| Model | Chamber size(WxHxFmm) |
| SW-1800CF | 100x100x100mm or 100/150mm |
| SW-1800CF | 120x120x130mm or 120/150mm |
| SW-1800CF | 150x150x150mm or 150/200mm |
| SW-1800CF | 200x200x200mm or 180/220mm |
| SW-1800CF | 200x200x300mm or 250/300mm |
Whether you’re in research, manufacturing, or materials science, this High-Temperature 1800 Degree Box Annealing Furnace stands out as an indispensable tool in your operations. Donot hesitate to Contact us at once for more information ,NanYang Sinowin Industry are not only a supplier but a reliable partner to assist you the safe solutions of the heat treatment
Technical Parameters of the High-Temperature 1800 Degree Box Annealing Furnace for heat treatment:
High-Temperature 1800 Degree Box Annealing Furnace |
|
| Main Specifications: | |
| Inside Chamber Size | DIA100/150MM 150/200MM 180/220MM 250/300MM |
| Standard Working Temperature | 1700oC ( continuous ) |
| Maximum Working Temperature | 1820oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Furnace structure | Double shell with fan cooling |
| Heating Element | MoSi2 heating elements |
| Thermocouples | B type |
| Working Voltage | AC 220/380V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 8KW |
| Outside Size | 550 x 540 x 820 mm |
| Net Weight | 170 Kg |
| SW series box furnaces are the most cost effective bench-top high temperature muffle furnace. The furnace consists of high quality alumina fiber brick and MoSi2 heating elements with special design, and furnace temperature is controlled by high precision SCR (Silicon Controlled Rectifier) digital controller with accuracy +/-1 deg oC and 30 segments programmable. It is an ideal tool for materials annealing and sintering in your research laboratory. | |
| Standard package included with the furnace | |
| Part description | Quantity |
| High Temperature Muffle Furnace | 1 pc |
| Heating Element, spare parts | 2 pcs |
| B type Thermocouples | 1 pc |
| Al2O3 Sample Plate | 1 pc |
| Al2O3 Furnace Door Block | 1 pc |
| Crucible Clip | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 pc |
| Standard Sizes: | |
| Model | Chamber size(WxHxFmm) |
| SW-1800CF | 100x100x100mm or 100/150mm |
| SW-1800CF | 120x120x130mm or 120/150mm |
| SW-1800CF | 150x150x150mm or 150/200mm |
| SW-1800CF | 200x200x200mm or 180/220mm |
| SW-1800CF | 200x200x300mm or 250/300mm |
