Product Description: High Temperature 1800C° Vertical Bottom Loading Elevator Furnace
Capable of reaching temperatures up to 1800 degrees Celsius, The High Temperature 1800C° Vertical Bottom Loading Elevator Furnace is ideal for a range of materials, including ceramics, metals, and composites. With its bottom-load design, it offers easy access to samples while maximizing workspace efficiency.
The characteristics of the High Temperature 1800C° Vertical Bottom Loading Elevator Furnace:
1).Big yield capacity and high productivity, especially used for heating treatment of small or medium products;
2).PID automatic control via current limiting phase angle fired thruster with 51 steps programmable,
to ensure uniform furnace temperature;
3).Loading from bottom, Lifting bottom controlled by electric, freely lift or down.Up and down limited switch,
double safety for bottom moving
Bottom Loading Elevator Furnace Application:
Bottom Loading Furnaces are widely used in the fields of metallurgy, ceramics, glass, machinery, analysis test, semiconductor, science & research and so on.
- Gravimetric Analysis;
- Sintering or Roasting or Forging or Calcining;
- Quantitative Analysis;
- Heat Treating or Preheating;
- Quenching or Hardening or Austempering
- Annealing or Tempering or Normalizing
- Stress Relieving
- Temperature Measurement
Technical Parameters of the High Temperature 1800C° Vertical Bottom Loading Elevator Furnace
Model: SW-1800BL
High Temperature 1800C° Vertical Bottom Loading Elevator Furnace |
|
| Main Specifications: | |
| Inside Chamber Size | 120/150MM Dia/H |
| Standard Working Temperature | 1700oC ( continuous ) |
| Maximum Working Temperature | 1820oC ( < 3 hrs) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Heating Element | MoSi2 heating elements |
| Working Voltage | AC 220V Three Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 4KW |
| Outside Size | 500 x 600 x 1200 mm |
| Net Weight | 200 Kg |
| SW-1800BL The single zone, high temperature, bottom loading furnace is capable of operating at temperatures up to 1650oC in air. The furnace utilizes 1800oC molydisilicide heating elements positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramic-fiber, high temperature insulation. It is an ideal tool for materials annealing and Sintering. | |
| Model | Chamber size(WxHxDmm) |
| SW-1800BL | 120x120x130mm or dia120H150mm |
| SW-1800BL | 150x150x150mm or dia150H200mm |
| SW-1800BL | 200x200x200mm or dia200H200mm |
| SW-1800BL | 200x200x300mm or dia200H300mm |
| SW-1800BL | 250x250x300mm or dia250H300mm |
| SW-1800BL | 300x300x400mm or dia300H400mm |
| SW-1800BL | 450x450x500mm or dia450H500mm |
With the High Temperature 1800C° Vertical Bottom Loading Elevator Furnace, you gain access to a powerful tool designed to meet the rigorous demands of your laboratory tasks. Experience the precision and dependability of our muffle furnace and elevate your research capabilities to new heights.
Choose our High Temperature 1800C° Vertical Bottom Loading Elevator Furnace for unparalleled performance and exceptional results in high-temperature applications. And Donot hesitate to Contact us at once for more information ,NanYang Sinowin Industry are not only a supplier but a reliable partner to assist you the safe solutions of the heat treatment
